Description
RK500-01 Soil/Liquid Temperature Sensor is used to measure the temperature of the soil or liquid medium, applied to the automatic meteorological station, soil temperature testing, pond or reservoir water temperature detection and other fields.The products can be used into the water or buried in the soil.Sensor with precision thermal resistance as a sensing component, built-in signal sampling and amplification, zero drift and temperature compensation function, has the characteristics of high measuring precision and good stability.
Feature
DIMENSION
PRODUCT DETAILS
Spesification
|
Item |
Technical Specification |
||
|
Range |
-20-+50?,-50-+100? |
||
|
Supply |
5VDC,12-24VDC |
||
|
Accuracy |
±0.5? |
||
|
Response Time |
<1s |
||
|
Output Signal |
PT100/PT1000 class A (3-wires),4-20mA,0-5V,RS485 |
||
| Operating Temperature | -50?-+80? | ||
|
Ingress Protection(probe) |
IP68 |
||
|
Storage |
10-60?@20%-90%RH |
||
|
Size |
4-20mA,0-5V,RS485: Probe:Ø19 ×119 mm,Transmitting module:Ø27*120mm PT100: Probe:Ø6 ×50mm |
||
|
Probe weight(unpacked) |
145g |
||
|
Housing material |
304 stainless steel |
||
