Water Level and Temperature Data Logger

Water Level and Temperature Data Logger



Inquiry

Description

Madgetech Data Recorder for Measuring Water Levels and Temperature up to 30 feet


Feature

  • Measure and Record Temperature Readings at Various Water Pressure Levels in Fresh Water
  • -40°C to 80°C Temperature Range over a Nominal Water Level Range of 30ft, 30 PSIA
  • Fully Submersible and IP68 Rated up to 50 feet
  • User Replaceable 3.6 Volt Lithium Battery with 1 Year Life (Included)
  • 2 Second to 12 Hour User-Selectable Sampling Rate (Configured in Software)

Spesification

Pressure Sensor Type: Semiconductor Strain Gauge
Nominal Range: 0 to 30ft
Accuracy (Calibrated): Nominal Range ±0.3% (Max) @ 25°C
Resolution: 0.05"
Response Time: 90% change in 1 ms
Repeatability: ±0.5% FSR; ±0.2% typical
Proof Pressure: 90 PSIA
Level Accuracy: ±2.5"
Temperature Sensor Type: Semiconductor
Measuremente Range: -40°C to 80°C (-40°F to 176°F)
Accuracy (Calibrated): ±0.5°C (±1.0°F) @ 0 to 50°C
Resolution: 0.1°C (0.2°F)
Data Storage Capacity 32,766 Total Readings (16,383 Temperature and Pressure)
Sampling Rate 2 Second to 12 Hours
Start Modes Immediate Start or Delayed Start (up to 6 Months)
Data Format Date/Time Stamp, °C, °F, °K, °R, PSI, inches, feet, millimeters, centimeters, meters (of column water)
Power Source (1) User-Replaceable 3.6 Volt Lithium Battery (Included)
Battery Life 1 Year @ 15 Minute Sampling Rate, 25°C
Dependant Upon Environment and Sampling Rate
Communication Type USB Dongle Connects Data Logger to PC Computer
(Requires #IFC200 USB Interface Package)
Baud Rate 2,400
Housing Enclosure 303 Stainless Steel
Time Accuracy ±1 Minute/Month @ 20°C
Operating Range Temperature: -40°C to 80°C (-40°F to 176°F)
Humidity: 0 to 100% RH
OS Compatibility Windows 8, 7, Vista and XP (32-bit and 64-Bit)
Standards Compliance CE, IP68
Weight 8 oz (220 grams)
Dimensions 5.7" x 1.25" (14.5 cm x 3.2 cm)
